MEV-Boost relay traces are a measurement trap

I started with the boring version of the question: which MEV-Boost relay has share?

The data immediately refused to answer it cleanly.

There are two things people casually call "relay share," and they are not the same thing.

One is bid volume: how many bids showed up in the relay bid trace table.

The other is accepted payload presence: whether the relay appears in the relay_names array for the payload that actually landed on-chain.

Those two views disagree hard.

For the seven complete UTC days from June 13 through June 19, there were 45,701 canonical MEV-Boost payloads in mainnet.fct_block_mev.

Ultra Sound appeared on 30,927 of them, or 67.7%. It also had 12,313 sole-relay payloads where no other relay appeared in the array.

But in mainnet.fct_mev_bid_count_by_relay, Ultra Sound had zero visible bid rows for the same window.

Titan is the cleaner contradiction because it exists in both tables. It had 20.4 million visible bid rows, only 2.5% of the visible bid trace volume. But it appeared on 20,323 accepted payloads, or 44.5% of canonical MEV-Boost payloads.

That is not a rounding error. That is a category error.

Here is the query for the main comparison. The important bit is that accepted_memberships is deliberately not exclusive. If the same winning payload came through Titan and Ultra Sound, both relays get counted, because that is what the table says happened.

WITH accepted_slots AS (
  SELECT count() AS mev_slots
  FROM mainnet.fct_block_mev FINAL
  WHERE slot_start_date_time >= toDateTime('2026-06-13 00:00:00')
    AND slot_start_date_time < toDateTime('2026-06-20 00:00:00')
    AND status = 'canonical'
    AND value IS NOT NULL
    AND value > 0
),
accepted AS (
  SELECT
    relay,
    count() AS accepted_memberships,
    countIf(length(relay_names) = 1) AS sole_relay_wins,
    sum(toFloat64(value)) / 1e18 AS value_eth
  FROM mainnet.fct_block_mev FINAL
  ARRAY JOIN relay_names AS relay
  WHERE slot_start_date_time >= toDateTime('2026-06-13 00:00:00')
    AND slot_start_date_time < toDateTime('2026-06-20 00:00:00')
    AND status = 'canonical'
    AND value IS NOT NULL
    AND value > 0
  GROUP BY relay
),
bids AS (
  SELECT
    relay_name AS relay,
    sum(bid_total) AS visible_bids
  FROM mainnet.fct_mev_bid_count_by_relay FINAL
  WHERE slot_start_date_time >= toDateTime('2026-06-13 00:00:00')
    AND slot_start_date_time < toDateTime('2026-06-20 00:00:00')
  GROUP BY relay_name
)
SELECT
  coalesce(a.relay, b.relay) AS relay,
  visible_bids,
  round(100 * visible_bids / sum(visible_bids) OVER (), 1) AS visible_bid_share_pct,
  accepted_memberships,
  round(100 * accepted_memberships / (SELECT mev_slots FROM accepted_slots), 1)
    AS accepted_payload_presence_pct,
  sole_relay_wins,
  round(value_eth, 1) AS value_eth
FROM accepted a
FULL OUTER JOIN bids b ON a.relay = b.relay
ORDER BY accepted_memberships DESC;

The top rows were:

Relay	Visible bid share	Accepted payload presence	Sole-relay payloads
Ultra Sound	no visible rows	67.7%	12,313
Titan Relay	2.5%	44.5%	7,255
BloXroute Max Profit	41.6%	34.6%	1,905
BloXroute Regulated	32.9%	32.4%	1,551
Aestus	3.0%	17.8%	476
Agnostic Gnosis	13.4%	6.5%	33

I checked the accepted-payload side against raw mev_relay_proposer_payload_delivered, deduped by (relay_name, slot, block_hash). It matched the refined table closely: Ultra Sound had 30,930 raw delivered payloads versus 30,927 refined memberships; Titan had 20,323 in both paths.

So this is not fct_block_mev inventing relays. The mismatch is between two different measurement surfaces.

The bid table is a view of visible bid traffic. It is useful if the question is "who is spamming the bid trace?" BloXroute Max Profit and BloXroute Regulated dominate that view: together they produced 74.5% of visible bid rows in the week.

It is the wrong table if the question is "which relays did accepted payloads come through?"

The other wrinkle is multi-homing. A block does not have to belong to one relay. The accepted payload can show up through several relays, and that has been getting more common.

SELECT
  toDate(slot_start_date_time) AS day,
  count() AS mev_blocks,
  round(avg(length(relay_names)), 3) AS avg_relays_per_payload,
  round(100 * countIf(length(relay_names) >= 4) / count(), 1) AS pct_four_plus_relays
FROM mainnet.fct_block_mev FINAL
WHERE slot_start_date_time >= toDateTime('2026-05-21 00:00:00')
  AND slot_start_date_time < toDateTime('2026-06-20 00:00:00')
  AND status = 'canonical'
  AND value IS NOT NULL
  AND value > 0
GROUP BY day
ORDER BY day;

On May 21, the average accepted payload listed 1.84 relays. On June 19, it listed 2.36. The share of payloads with four or more relays went from 15.1% to 26.9%.

That changes how I read relay data.

There is no single clean "relay share" unless you first say which surface you mean. Bid rows measure bid visibility. relay_names measures accepted-payload delivery paths. Sole-relay payloads measure something narrower again.

Mix those up and you get nonsense like "Titan has 2.5% share" while it appears on almost half of accepted MEV-Boost payloads.

The relay market might be consolidating. It might not be. This query does not prove either.

What it proves is simpler and more annoying: the obvious denominator is wrong.
